842
Brake Rod Adjuster Nut. Fits 1952-78.
VT No. 37-8461
Rear Brake Cable Assembly fits drum brake 1975-78 mod-
els, 2 types.
VT No. OEM Year
36-1975 38634-75 1975-76
36-1977 38634-77 1977-78
Rear Chain Adjuster Sets are heat treat-
ed and include nuts. Fits 1952-78.
VT No. Finish
7703-2 Chrome
9020-2 Cadmium
Chrome Brake Light Switches
VT No. # OEM
Type
Fits
32-7785 A 72004-52 Push
1959-66
32-0547 B 72004-75 Pull
1975-76
32-0552 B Black
Pull
As Above
32-0424 C 72004-70 Push
1967-74
32-0572 D Kit
Pull
1975-76
32-0551 E Kit
Push
1977-78
13-0218 Spring
1969
C
B
1958-69 XLCH Switch Mount Kit replaces
72011-59 bracket, 5902 (2) spacer.
VT No. 32-9028
E
Universal Black Mechanical Brake Lamp Switch
includes clamp and spring. Pull is on.
VT No. 32-0421
A
D
1954-78 XL Rear Brake Components, Drum Type.
VT No. #
OEM
Item /Type
10-2505 22 47757-52
Bushing, pr
44-0326 23 7986
Axle Nut Kit, Chrome
36-1975 25 38634-75
Cable Assembly 1975-76
36-1977 25 38634-77
Cable Assembly 1977-78
13-0205 27 40521-75
Spring, Stop Light & Switch
23-0438 28 41401-52
Drum & Sprocket, Black
23-0437 28 Complete
As above, Chrome
19-0011 29 41470-70
Sprocket only, Black w/rivets
8811-16 6-19 Chrome
Lug Bolt Set
8812-16 6-19 Cadmium
3970B & 7725 Nut
44-0217 30 41551-52
Rear Axle, Chrome
Rear Axle Kit
44-0317 31 41598-52
Collar, Zinc
44-0500 31 41598-52
Collar, Chrome
44-0324 32 41600-55
Spacer, Chrome
23-0396 33 41620-75
Splined Arm 1975-76
23-2267 34 41662-54
Side Plate 1954-72
23-3067 34 41662-74A Side Plate 1973-74
23-2268 34 41662-75
Side Plate 1975-78
13-0144 35 41667-75
Spring, Lever, ea
13-0146 39 41835-69
Shoe Springs, pr
23-0411 37 41730-52
Locating Block, Zinc
8937-3 38 41730-73
Spacer Pivot Stud Kit
43 41882-73
Bolt, 3pc
44 41883-73
Washer, Cadmium
As Above, Chrome 3pc Kit
23-0127 37-41-52
Piv ot Stud Kit 3pc 1952-72
23-0409 41 41876-54
Pivot Stud 1954-72
23-0410 41A 41876-73
Pivot Stud 1973-78
23-0412 42 41882-52
Stud Nut 1954-72
9207-4 37-41-42
Piv ot Stud Kit, Chrome
As Above
Pivot Stud Kit, Cadmium
23-0397 45 41925-52
Rear Lever Chrome
23-0399 46 42252-52
Brake Rod, 54-66 Short, Chr.
42252-52
As above, Cad w/nut
42252-52
As above, Parkerized
23-0398 46 42253-67
Brake Rod, Long 67-74, Chr
42253-67
As above, Cad w/nut
37-8461 47 42264-52
Adjuster Nut 1952-78
23-0421 48 42269-30
Clevis Pin 1954-74
23-0408 51 42410-52
Pedal, Chrome 1952-74
23-0400 52 42420-75
Pedal, Chrome 1975-76
23-0404 52 42410-75A Pedal, Chrome 1977-79
13-0153 54 42427-52
Return Spring 1954-78
23-1997 55 42549-52
Cross Shaft 1954-74
23-1998 55A 42549-75
Operating Shaft 1977-79
23-3066 56 44264-54
Cam Brake 1954-78
23-0505 40 44432-54
Lining & Rivet Set 1954-78
37-9172 58 45052-75
Cable pin
23-0503 60 44401-49B Brake Shoe Set
Anchor Studs for Backing Plates in
chrome or cadmium finish.
VT No. Years Finish
9207-4 1954-72 Chrome
9208-4 1954-72 Cadmium
8936-3 1973-78 Chrome
8937-3 1973-78 Cadmium
23-0410 1973-78 Zinc
Chrome Rear Brake
Arm replaces 41925-52.
Fits 1952-78.
VT No. 23-0397
1954-78 Mechanical Brake Parts
