Home



825
1970 and Earlier Clutch.
VT No. # OEM
Item
17-1111 4 8215
5
/32 x
13
/16 x
9
/32 Rivet
18-3640 5 33162-67 Starter Ring Gear
17-1116 6 33379-57 Starter Ratchet 9T
18-2331 7 34897-53 Screw Retainer
18-1140 8 37201-54 Release Worm and Lever
18-1138 9 37210-47 Release Worm Cover
13-0137 10 37222-52 Worm Lever Spring
17-1158 12 37279-56 Release Rod Set 56-66 XLs 1967-69 XLCH
17-1157 12 37280-67 Release Rod Set 1967-69 XLH, 1970 XLCH
14-0125 15 37339-53 Release Rod Oil Seal
N/A
16 37345-52 Release Rod Oil Seal Ret.
12-0539 17 37526-56A Clutch Hub Nut
12-0540 18 37527-67A Clutch Hub Nut
17-0912 19 37533-52A Clutch Hub Lockwasher
17-0090 20 37535-52 Clutch Hub Spacer
18-3157 21 37556-57B Hub Assembly, 1957-69 XLCH
18-3161 21 37557-67 Hub Assembly, 1967-70 XLH, 1970 XLCH
12-0372 22 37568-67 Clutch Hub Bearing Inner Race
12-0510 23 37581-52 Large Hub Stud Nut
12-0574 24 37582-52 Small Hub Stud Nut
Nut Set 3 each, #23 & #24
18-8232 25 37584-64 Clutch Hub Stud (6) 1964-66
18-3123 25 37584-67 Clutch Hub Stud (6) 1967-70
17-0091 28 37721-54 Sprocket Hub Washer
12-0328 29 37722-52 Clutch Sprocket Needle Bearing
17-0020 30 37731-52 Washer, Sprocket Bearing, 0.0955" thick
17-0021 30 37732-52 Washer, Sprocket Bearing, 0.0975" thick
17-0022 30 37733-52 Washer, Sprocket Bearing, 0.0980" thick
17-0024 30 37735-52 Washer, Sprocket Bearing, 0.0925" thick
Washer Sprocket Bearing, 0.1010" thick
17-0092 30 As Above Assortment, 1 each of above
14-0128 31 37740-57 Sprocket Oil Seal
14-0129 32 37741-67 Clutch Hub Oil Seal
18-3637 33 37760-52 Clutch Cover
15-0212 34 37762-52 Clutch Cover Gasket
18-3635 35 37876-52 Releasing Disc
18-1113 36 37985-52A Friction Plate Raybestos (7)
18-1115 37 37992-52 Drive Plate (7)
18-1141 38 38013-52 Pressure Plate
18-1116 39 38016-52 Backing Plate
13-0140 40 38076-52 Spring (6)
18-3642 41 38101-52 Backing Plate, Spring Cup (6)
18-1139 42 38130-54 Adjusting Screw
12-0519 43 38135-50 Adjusting Screw, Locknut
1970 & Earlier XL Clutch
1954-70 Clutch
Release Kits.
VT No. 18-1211
Clutch Rod Installation for 17-
1166 and 17-1165. See page 814.
VT No. Year Models
17-1158 1956-66 XLH
1967-69 XLCH
17-1157 1967-69 XLH
1970
XLCH
Assembly Order Illustration
Early XLH & XLCH Sprocket Cover. Kick
and electric with starter cut out. Replaces
34871-67B, kick only replaces 34782-57A
on 1952-70 Sportsters. Complete cover
assembly includes cover, release worm
adjuster screw, nut, oil deflector, spring
and kicker spring stud.
VT No. Type
43-0114 Polished Kick & Electric Cover
43-0135 Polished Kick Cover Only
43-0136 Chrome Kick Cover Only
18-1211 Release Kit
8886-2 Stud, Chrome
8887-2 Stud, Cadmium
Stock Sprocket Kicker Cover Screws
VT No. Years Type/Finish
8884-2 1954-70 Chrome
8885-2 1954-70 Cadmium
8886-2 1952-70 Pipe Mount Stud
8887-2 1952-70 As Above, Cadmium
1952-67 XLCH Cast Sprocket Cover fea-
tures early Rib design, includes worm and
hardware, replaces 34874-52A.
VT No. 43-0133
1954-70 Clutch Release Parts.
VT No. OEM
Part
Kit
18-1138 37210-47 Cover
18-1139 38130-54 Screw
12-0519 38135-50 Nut
18-1140 37201-54 Worm
13-0137 37222-52 Spring (10)
1952-70 Clutch Cable with adjuster.
VT No. Item
36-0406 Cable Assembly
37-8460 Adjuster Only
Rubber Cable Oiler Boot
replaces 38690-55, for XL
1955-80. 5 pack.
VT No. 28-0401
Clutch Cable Bracket
secures cable to frame on
1952-E70 XL models.
Parkerized finish. Replaces
38676-52
VT No. 37-9160
Replica Clutch Adjuster
Sleeve. Fits 1954-71,
7
/
16
"
hole levers. Zinc plated.
VT No. 37-8460
