  • 626


626
Magneto Replacements fit Fairbanks Morse and most after-
market units. Covers include gasket and screws.
VT No. # OEM
Item
15-0149 A 29550-55
Gasket
Clear Cover
32-0645 B 29530-55A Black Cover
32-0716 D 29524-55A Coil
13-9208 E 29560-55
Coil Springs, 10 pk
32-0646 F 29600-62
Magneto Plate 1962-64
32-7784* G 32727-63
Large Condenser
31-0485 H 29607-65
Control Arm, XL
32-0515 I 29600-65
Upper Adapter Plate 1965-70
32-0516 J 29604-65
Lower Adapter Plate 1965-70
Points and Condenser Kit
29550-55
Top Gasket
*Note: Regulates light intensity on 1959-70 XLCH models.
Joe Hunt H-4 Automatic Advance Vertical Magnetos for Big
Twins features include H4 automatic advance for easier starting
and hotter spark, aluminum cam cover in either natural or pol-
ished finish (no frame, pipe, or-brake pedal modification are
required) and rare Earth magnets that never need to be
recharged.
VT No. Fits
Finish
32-1296 1970-92 Natural
32-1250 1970-92 Polished
Magnetos
Accel Electronic Advance Distributor with rev limiting for
1930-52 45, 1936-47 SV Big Twin and 1952-70 XL models.
Features adjustable electronic advance curves, single on dual
fire modes and CNC machined billet housing. Use with a 3 ohm
coil.
VT No. 32-7804
Accel Electronic Advance Distributor with rev limiting for
1936-69 Big Twins. Features adjustable electronic advance
curves, single on dual fire modes, CNC machined billet housing
and can be installed without removing cylinder head. Use with a
3 ohm coil.
VT No. 32-7803
Distributor
Joe Hunt Magneto fits 1930-73 45 Side
Valve and 1952-70 K & XL models. Order
related mount plates separately.
VT No. Item
32-1297 Magneto
32-0646 Inner Plate
32-0515 Outer Ring
32-0485 Control Arm
