746
45 Front Axle and Brake Hardware fits 1930-52.
VT No.
OEM
Item
7811
Axle nuts, parkerized
7811
Axle nuts, chrome
7811
Axle nuts, cadmium
12-0157 8860
Balls, 50pk
44-0533 9851
Grease Fitting, 10 pk
37-0511 9852
90 Grease Fitting, 5 pk
37-9027 9968
Early Frame Mount Cable Clamp
37-9289 9974
Lower Cable to Fork Clamp
37-8776 9980
Front Brake Cable Clamp
44-2005 43617-30
Axle Sleeve
44-2006 43630-30
Retaining Ring, 5 pk
44-2002 43632-44
Cone Seal
44-2003 43635-30
Lockwasher
Cone Nut for Sleeve
44-2007 43640-30
Left inner dirt guard
49-1963 43871-30
Axle
43885-30
Nut and Oil Seal
Includes 43633-44
Retainer, chrome
As Above
Cadmium
As Above
Parkerized
49-0200 44145-41
Backing Plate 1941-52
10-0736 44180-30
Backing Plate Bushing
49-2012 44223-28
Springer Fork Brake Bushing
49-2563 44226-36
Stud
44229-40
Lock Tab
44231-38
Nut
8010-10 44226-36
44223-28 Shackle Rebuild Kit,
44231-38
included 2 studs, 2 bushings, lock,
44229-40
grease fittings, and hardware.
44231-38
49-2604 44211-40
Shackle Bar, Black
Pivot Stud
49-0245 44250-29
Fitting Extension
49-0211 44265-31
Brake Cam
37-8941 44270-36
1936-48 Brake Cam Washer
49-0063 44307-31
Front Brake Operating Arm
49-2604 44211-40
Shackle Bar, Black
49-0245 44250-29
Fitting Extension
49-0211 44265-31
Brake Cam
37-8941 44270-36
1936-48 Brake Cam Washer
49-0063 44307-31
Front Brake Operating Arm
49-2576 44346-29, 45 Front Brake Plate Cover Kit
44340-30
44348-29
44344-29
44342-29
37-9290 44350-30
Wheel Cover Plate Stud
23-1992 44406-31
Shoe Set
44405-31
23-0518 44427-35
Brake Lining Only
49-0212 44450-35
Brake Shoe Pivot Stud
49-2575 44476-35
Locking Plate
13-0208 44486-28
Spring Set
26-2126 45002-41
Lever Assembly Polished
26-2127 45002-41C Lever Assembly Chromed
36-1994 45085-30
Brake Cable Inner/Outer 1941-57
Brake Cable Outer 1928-40
49-0422 45085-30
1930-57 Brake Cable,Inner /Outer
Includes 45102-39
Cable Oil Cup Kit
45085-30
Cable Ferrules 1941-57
36-2567 45153-28
Inner Cable only
45162-41
Cable Adjuster, 1941-57
45162-41
As Above, Chrome
45162-41
As Above, Parkerized
4165-28
Cable Adjuster 1928-40 Cadmium
4165-28
As Above, Parkerized
4165-28
As Above, Chrome
37-8773 45172-28
Lower Cable Clamp, Black
1930-52 45" Front Brake
45" Solo Brakes
VT No. # Item
49-2576 A Kit
37-9290 B Studs to mount cover
A
B
45 Front Brake Plate Cover Kit. Includes pieces pic-
tured.
45 Front Brake Drum Complete includes bearings and axle.
Brake plate required.
VT No. 49-0454
45 Solo Front Wheel
45 Solo Front Wheel Assemblies include rim,
replica original finish hub and bearings laced
with stainless steel spokes.
VT No. Size Rim
52-0756 16" Chrome
52-0757 16" Black
52-0758 18" Black
52-0759 18" Chrome
45 Rear Brake Parts for 1941-52 Solo Models
VT No. OEM
Item
23-1740 41401-41 Drum Complete, Black
Drum Complete, Chrome
49-2555 41652-37 Backing Plate, Black
23-0760 41692-36 Brake Cam Shim
19-0010 41475-35 Sprocket Kit with Ring
19-0089 41421-35 Dust Ring only
23-1751 41806-41 Shoe Set Complete
13-0208 44486-28 Spring Set
23-0736 41849-41 Linings, pair
49-0077 4054-35 Rear Cam
Rear Cam, Wide
49-2574 41876-41 Pivot Stud
49-2575 44476-35 Lock Plate
49-0914 42566-35 Bell Crank
49-0179 41925-41 Rear Arm
49-2598 41925-41 As Above, Chrome
49-0104 4073-39 Front Rod, Parkerized
49-0105 4065-35 Rear Rod, Parkerized
45
Black Backing Plate Assembly includes backing plate, arm, shoes, springs,
speedometer drive & cam completely assembled.
VT No. 49-0960
45
Rear
Brake
Parts
Brake Rods in chrome or parkerized.
Chrome Parkerized OEM
Ye ar
Model Type
4073-39 1939-5245 Solo
Front
4065-35 1935-52 45 Solo Rear
4063-30 1930-35 VL
Front
4065-30 1930-35 VL
Rear
